Tenderfoot TZVCA 4 Channel Four Quadrant Mixing VCA
The TZVCA is a 4-channel four-quadrant mixing VCA module and a true powerhouse of sonic exploration.
Each of the four channels has an array of features. Unleash your creativity with the switchable standard or thru-zero (four-quadrant) mode, offering you a world of possibilities for modulating, manipulating, and inverting your audio and CV signals. A four-quadrant VCA allows you to use each channel as a CV-controlled attenuverter, and when used for audio signals it can become a ring modulator.
Each channel also features a dial to choose between exponential or linear response, exploring the full spectrum of sounds in between.
The master mix output combines all channels not utilising their individual outputs. This master mix output offers a very convenient way to blend and merge your audio or CV, creating complex and captivating soundscapes. Additionally, TZVCA grants you two other outputs, one blending channels 1 and 2, and the other for channels 3 and 4.
In addition to all of these features, multiple TZVCA modules can be chained together via a ribbon cable on the back of the circuit board. With the ability to link these modules seamlessly, you can increase the number of channels at your disposal for mixing, modulation, and CV manipulation.
Product Specs
- Item Number: 30152
- Make: Tenderfoot
- Model: TZVCA
- Condition: Brand New
- Finish: Black
- Categories: keyboards-and-synths ⇒ eurorack
- Function: VCA Quad
- Made In: Taiwan
- MPN: TDFT17
- Modular Grid: Eurorack ⓘ ＋
- Dimensions*: 20 HP 22 mm deep
- Power*: 115 mA +12V 110 mA -12V ? mA 5V
* User contributed details
