Weston Precision Audio SV1 Dual/Stereo VCA
The SF1 is a dual voltage controlled filter (VCF) module designed to be used either as a pair of identical, but separate VCFs, or as a stereo filter.
9 possible output responses are available from the 2 concurrent outputs for each filter/channel. "Link" mode is ideally suited for stereo applications and allows both filter's cutoff, resonance, and cutoff/resonance CV to be simultaneously using the left-hand controls/inputs. The outputs are routed to a CV-controlled panner/crossfader, allowing modulation of the spacial location of each filter.
Features
- Dual/Stereo VCA module
- Offers both vintage transistor and modern chip-based VCAs per channel
- Input with up to +6dB input gain
- Bias controls
- CV attenuators with up to 2x gain
- Optional stereo link feature
- Overdrive on/off switch
- Optional zero-crossing detection circuit to reduce clicks from snappy envelopes
Specs
- 18HP module size, 25mm Deep
- Power: 120mA +12V / 120mA -12V
Video: https://youtu.be/H6GdoDR4gZM
Product Specs
- Item Number: 36893
- Make: Weston Precision Audio
- Model: SV1
- Condition: Brand New
- Finish: Black
- Categories: keyboards-and-synths ⇒ eurorack
- Function: Distortion Dual/Stereo Mixer VCA
- Made In: United States
- MPN: WPA-10194
- Modular Grid: Eurorack ⓘ ＋
- Dimensions: 12 HP 33 mm deep
- Power: 70 mA +12V 70 mA -12V 0 mA 5V
