Module A-111-3 is an extremely space-saving precision VCO/LFO with a 4HP panel only. Essentially it's the same basic circuit as the A-111-2 but with reduced features:

• Triangle core
• Fully analog design
• Min. 15 octaves pitch range in each mode (VCO/LFO):
• VCO mode: typ. 0.5 Hz - 20 kHz (with appropriate external CV)
• LFO mode: typ. 0.001 Hz - 40 Hz (with appropriate external CV)
• Range switch so that the module can be used as VCO or LFO (in LFO mode all frequencies about 1/500 compared to VCO mode)
• About 24 octaves total in both modes (typ. 0.001 Hz - 20kHz)
• Perfect 1V/octave tracking over min. 10 octaves (typ. 16Hz - 16kHz in VCO mode)

Read More

Brand new with warranty.

Product Specs

• Item Number: 9489
• Make: Doepfer
• Model: A-111-3V Micro Precision VCO Vintage Edition
• Condition: Brand New
• Finish: Silver
• Categories: keyboards-and-synths ⇒ eurorack
• Function: LFO Oscillator
• Made In: Germany
• MPN: A-111-3V
• EAN: 4250711111113
• Modular Grid: Eurorack ⓘ ＋
• Dimensions*: 4 HP 65 mm deep
• Power*: 40 mA +12V 40 mA -12V 0 mA 5V

* User contributed details
